Product Description
Features
- 8" Stainless Steel Capstans
- 20" Diameter Stainless Steel V-Sheaves
- Stainless Steel Horizontal Roller with Stainless Steel Bearings
- Stainless Steel Splitter
- Large Stainless Steel Idler Rollers
- Large Diameter Stainless Steel Idler Shafts equipped with Stainless Steel Bearings
- All 'SeaCatcher' Winch Housings are of Sturdy Steel Construction with Large Radius Edges, then Hot-Dipped Galvanized
- All 'SeaCatcher' and 'PurseDominator' Purse Winches come Standard with the E-STOP Emergency Kill Switch Installed into the Winch Horn
- Powerful CharLynn 10,000 Series Hydraulic Motors, in sizes compatible with your Hydraulic System
- Winch weighs Approximately 1000 Lbs
Optional
- 6" Taller
- E-Stop Control Valving with Wiring Diagram
Winch Performance
- Based upon 40 GPM @ 1500 PSI
- With CharLynn 10000/57 Hydraulic Motor
- Capstan Line Pull: 9,200 Lbs
- Capstans Turn 51 RPM Under Loaded Conditions = 108 FPM
- Sheave Line Pull: 4,900 Lbs = 200 FPM
Product Videos
Custom Field
HYDRAULIC MOTOR CHARLYNN 10000/57 (RECOMMEND 40 GPM @ 1500 PSI)
CAPSTAN STYLE STAINLESS STEEL 8" WORKING DIAMETER-KNURLED
CAPSTAN & SHEAVE SPEED 51 RPM
CAPSTAN LINE PULL 9,250 LBS
CAPSTAN LINE SPEED 106 FEET PER MINUTE
SHEAVE STYLE STAINLESS STEEL 20" DIAMETER
SHEAVE LINE PULL 4,625 LBS
SHEAVE LINE SPEED 215 FEET PER MINUTE
IDLER ROLLER MATERIAL STAINLESS STEEL
IDLER ROLLERS - BEARING TYPE & MATERIAL BALL BEARING - STAINLESS STEEL
HORIZONTAL ROLLER MATERIAL STAINLESS STEEL
HORIZONTAL ROLLER - BEARING TYPE & MATERIAL BALL BEARING - STAINLESS STEEL
DRIVE CHAIN MATERIAL TYPE DAC PROTECTED STEEL ROLLER CHAIN
SHEAVE STUD MATERIAL TYPE 17-4 STAINLESS STEEL HEAT TREATED
SHEAVE SHIM KIT MATERIAL TYPE STAINLESS STEEL SHIMS
WINCH HOUSING MATERIAL STEEL FABRICATED - HOT DIPPED GALVANIZED
