Product Description
Features
- Winch Frame is 6" taller than the Standard 2N-S Purse Winch
- Equipped with 'S-CLASS' Cast Iron Capstans
- 17" Diameter Bronze Pursing V-Sheaves
- 5" Diameter Stainless Steel Idler Rollers that are Ball Bearing equipped
- Large Diameter Stainless Steel Idler Shafts
- Stainless Steel Horizontal Roller with Ball Bearings
- Stainless Steel Splitter
- Proven/durable CharLynn 6000 Series Hydraulic Motor Drive
- Provided Grease Panel makes lubricating a breeze without having to remove any inspection cover plates
- E-STOP Emergency Kill Switch Installed into the Winch Horn (E-Stop Control Valving with Wiring Diagram is Available as an option)
- Winch Housing is of Sturdy Steel Construction with Large Radius Edges, then Hot-Dipped Galvanized
- Powerful CharLynn 6,000 Series Hydraulic Motor is used exclusively for maximum performance
- Winch weighs approximately 700 Lbs
Winch Performance
- Based upon 28 GPM @ 1500 PSI
- With CharLynn 6000/30 Hydraulic Motor
- Capstan Line Pull: 5,200 Lbs
- Capstans Turn 70 RPM
- Under Loaded Conditions = 120 FPM
- Sheave Line Pull: 3,000 Lbs = 230 FPM
Product Videos
Custom Field
HYDRAULIC MOTOR CHARLYNN 6000/30 (RECOMMEND 28 GPM @ 1500 PSI)
CAPSTAN STYLE CAST IRON 7" WORKING DIAMETER
CAPSTAN & SHEAVE SPEED 69 RPM
CAPSTAN LINE PULL 5,350 LBS
CAPSTAN LINE SPEED 118 FEET PER MINUTE
SHEAVE STYLE BRONZE 17" DIAMETER
SHEAVE LINE PULL 2,800 LBS
SHEAVE LINE SPEED 250 FEET PER MINUTE
IDLER ROLLER MATERIAL STAINLESS STEEL
IDLER ROLLERS - BEARING TYPE & MATERIAL BALL BEARING - STEEL
HORIZONTAL ROLLER MATERIAL STAINLESS STEEL
HORIZONTAL ROLLER - BEARING TYPE & MATERIAL BALL BEARING - STEEL
DRIVE CHAIN MATERIAL TYPE STEEL ROLLER CHAIN
SHEAVE STUD MATERIAL TYPE G80 STEEL STUDS
SHEAVE SHIM KIT MATERIAL TYPE UHMW SHIMS
IS E-STOP CONTROL VALVING INCLUDED? YES! E-STOP SWITCH IS INSTALLED INTO WINCH HORN AND CONTROL VALVING IS INCLUDED AT NO ADDITIONAL CHARGE!
WINCH HOUSING MATERIAL FABRICATED STEEL - HOT DIPPED GALVANIZED
